Level sensor with rotary vane - SOLIBA PRP

Description :

SOLIBA PRP rotary vane level sensors with plastic housing (ABS) are used to detect a high or low level of bulk products in storage silos, hoppers and containers.

Placed on a hopper or silo, the SOLIBA PRP rotary vane level detector is rotated by a motor. The operation of the detector is simple, when the pallet is covered with the bulk product, the rotation is stopped, the signal is cut and gives the signal that the level is reached.

When the level of the bulk product decreases, the pallet is released, the signal is restored and the engine restarts to fill the silo or the hopper.

The different types of pallet or process connection make it possible to adapt to the tanks and the products to be detected according to the density of the product.



ATMI
 Technical data sheet - SOLIBA PRP  (PDF 1004Ko)

Usage tips :

  • The SOLIBA PRP rotary vane level detector can also be used as an intermediate level to detect a given level
  • For the low level, we recommend using an aluminum reinforcement flange for better durability over time.

Applications :

Technical caracteristics :

Operation By rotation
rotation speed 5 rpm
Power supply 250 VAC / VCC 50/60 Hz option: 24, 48 VAC / VDC
Cut out power 2 A
Allowed temperature -20 ºC ... +60 ºC
Protection index IP 65
Housing material ABS casing
Pallet AISI 304 or 316 stainless steel
Weight 800 g
Dimenssion Height : 130 x 105 x 235 mm
Product density 0.3 t / m3 ... 2.5 t / m3
