Level regulator with internal ballast - AQUA MEDIUM

Description:

AQUA MEDIUM

This robust level regulator is equipped with internal ballast. As the liquid level reaches the regulator, the mechanical switch inside will tilt, thus closing or opening a circuit connected to an electrical panel.

The AQUA MEDIUM is capable of penetrating the thick layers of grease found on waste water pumping stations, and it is the ideal level regulator for limited spaced applications.

This model is also available in a bigger version. See AQUA XL. The AQUA MEDIUM level regulator is not suitable for agitated liquids. Please choose our float switch models: BIP STOP, AT 120, or ATS 165.

ATMI
 Technical data sheet - AQUA MEDIUM  (PDF 468Ko)

Advantages:

ECONOMIC

ECOLOGIC

RELIABLE

WATERPROOF

ROBUST

CUSTOMIZABLE

Applications:

Technical caracteristics:

Switching angle +/- 10°
Allowed fluid density 0,95 to 1,05
Power supply 12, 24, 48 VAC /VCC -  250 VAC /VCC 50/60 Hz
Cut out power 16 (6) A (16 A resistive; 6 A inductive)
Maximum pressure 3,5 bars
Allowed temperature 85 °C
Protection index IP 68
Housing material Copolymer Polypropylene
Cable 3 x 1 mmm˛ PVC, Neoprene
Weight 400 g
Dimenssion Height : 140 mm - Diam : 70 mm
Ballast Internal ballast
Cable lenght 5, 6, 10,13, 15, 20, 25 et 30

Recommended accessories:

FIXCAB

Fixing accessory strongly recommended for all suspended floats

  • Avoid the risk of deterioration of the cable
  • Easy installation
  • Precise cable adjustment at all times
FIXCAB
ATMI
 Technical data sheet - FIXCAB  (PDF 335Ko)
