Small float switch for narrow access tank TUBA 1"

Description

TUBA 1"

This float level switch is a small diameter tubular float that has been designed to fit tanks and cisterns having restriced access.

Its small 1" diameter allows it to pass through the narrow openings usually found on the side walls of tanks. As the liquid level reaches the float, the mechanical switch inside will tilt, thus closing or opening a circuit connected to an electrical panel.

Thanks to its +/-20º switching angle, the TUBA float level switch ensures a very precise level measurement..

The installation is possible up to a water depth of 55 meters.

The TUBA 1'' float level switch can be installed in 3 ways :

fixed to a cane, vertically suspended on the cable with external ballasts, or horizontally mounted on the tank sides with a gland.



ATMI
 Technical data sheet - TUBA 1"  (PDF 486Ko)

Advantages

ECONOMIC

ECOLOGIC

RELIABLE

WATERPROOF

LOW DIAMETER

CUSTOMIZABLE

Applications

Technical caracteristics

Switching angle +/- 20°
Allowed fluid density 0,75 to 1,50
Power supply 250 VAC /VCC 50/60 Hz
Cut out power 12 (6) A (12 A resistive; 6 A inductive)
Maximum pressure 5,5 bars
Allowed temperature 85 °C
Protection index IP 68
Housing material Copolymer Polypropylene
Cable 3 x 1 mmm˛ Neoprene
Weight 60 g
Dimenssion Height : 180 mm - Diam : 29 mm
Ballast (optional) 175 g résine chargée
Cable lenght 2, 3, 5, 6, 10,13, 15, 20, 25 m

Recommended accessories

FIXCAB

Fixing accessory strongly recommended for all suspended floats

  • Avoid the risk of deterioration of the cable
  • Easy installation
  • Precise cable adjustment at all times
FIXCAB
ATMI
 Technical data sheet - FIXCAB  (PDF 335Ko)

AJUSTABLE BALLASTS

Adjustable ballast are essential for good operation of the floats level switches.

  • Set the rotation point of the float.
  • Allow the float to work in a wide range of densities
  • Precise adjustment at any time to adapt to any turbulence in the liquid
ADJUSTABLE BALLASTS
ATMI
