Float switch for aggresive and 150°C high temperature liquids

Description

TUBA 150 C

This small tubular float level sensor is equipped with a TEFLON cable and a specially designed PTFE housing for extremely aggressive liquids, such as for example sulfuric acid and very hot liquids reaching temperatures up to 150°C.

The TUBA 150 C level sensor has a ball inside a sealed polypropylene cylinder that will activate a microswitch according to its position. This principle is extremely reliable.

The small diameter of this float (Ø 55 mm) allows its introduction by small holes often placed on the vertical walls of the tanks.

ATMI
 Technical data sheet - TUBA 150C  (PDF 469Ko)

Advantages

ECONOMIC

ECOLOGIC

RELIABLE

WATERPROOF

RESISTANT TO CHIMICALS LIQUIDS

USE UP TO 150°C

Applications

Technical caracteristics

Switching angle +/- 20°
Allowed fluid density 0,75 to 1,50
Power supply 24 --250 VAC/DC-MAX 60 VA
Cut out power Max. 1 A, 60 VA
Maximum pressure 1 bars
Allowed temperature 150 °C
Protection index IP 68
Housing material PVDF
Cable 3 x 0.22 mmm² PTFE
Weight 80 g
Dimenssion Height : 130 mm - Diam : 55 mm
Ballast without
Cable lenght 5, 10, 15, 20, 25 m

Recommended accessories

FIXCAB

Fixing accessory strongly recommended for all suspended floats

  • Avoid the risk of deterioration of the cable
  • Easy installation
  • Precise cable adjustment at all times
FIXCAB
