Level sensor with rotary vane - SOLIBA PRA

Description :

SOLIBA PRA rotary vane level sensors with aluminium housing  are used to detect a high or low level of bulk products in storage silos, hoppers and containers.

Placed on a hopper or silo, the SOLIBA PRA rotary vane level detector is rotated by a motor. The operation of the detector is simple, when the pallet is covered with the bulk product, the rotation is stopped, the signal is cut and gives the signal that the level is reached.

When the level of the bulk product decreases, the pallet is released, the signal is restored and the engine restarts to fill the silo or the hopper.

The different types of pallet or process connection make it possible to adapt to the tanks and the products to be detected according to the density of the product.



ATMI
 Technical data sheet - SOLIBA PRA  (PDF 965Ko)

Usage tips :

  • The SOLIBA PRA rotary vane level detector can also be used as an intermediate level to detect a given level
  • For the low level, we recommend using an aluminum reinforcement flange for better durability over time.

Applications :

Technical caracteristics :

Operation By rotation
Rotation speed 1 rpm
Power supply 250 VAC / VCC 50/60 Hz option: 24, 48 VAC / VDC
Cut out power 2 A
Allowed temperature -20 ºC ... +60 ºC
Protection index IP 65
Housing material Aluminium
Pallet AISI 304 or 316 stainless steel
Weight 2500 g
Dimenssion Height : 143 x 175 x 290 mm
Product density 0.3 t / m3 ... 2.5 t / m3

Documentation(s):

SOLIBA PRP ] [ SOLIBA PRA ]
