Float switch for very aggresive and 125°C high temperature liquids

Description

TUBA 125 C

This small tubular float level sensor is equipped with a PTFE cable and a specially designed PVDF housing for extremely aggressive liquids, such as for example sulfuric acid and very hot liquids reaching temperatures up to 125°C.

The TUBA 125 C level sensor has a ball inside a sealed polypropylene cylinder that will activate a microswitch according to its position. This principle is extremely reliable.

The small diameter of this float (Ø 40 mm) allows its introduction by small holes often placed on the vertical walls of the tanks.

ATMI
 Technical data sheet - TUBA 125C  (PDF 469Ko)

Advantages

ECONOMIC

ECOLOGIC

RELIABLE

WATERPROOF

RESISTANT TO CHIMICALS LIQUIDS

USE UP TO 125°C

Applications

Technical caracteristics

Switching angle +/- 20°
Allowed fluid density 0,75 to 1,50
Power supply 230 VAC /VCC 50/60 Hz
Cut out power 6 (4) A (6 A resistive; 4 A inductive)
Maximum pressure 5,5 bars
Allowed temperature 125 °C
Protection index IP 68
Housing material PVDF
Cable 3 x 0.22 mmm˛ PTFE
Weight 90 g
Dimenssion Height : 205 mm - Diam : 40 mm
Ballast PTFE
Cable lenght 5, 10, 15, 20, 25 m

Recommended accessories

FIXCAB

Fixing accessory strongly recommended for all suspended floats

  • Avoid the risk of deterioration of the cable
  • Easy installation
  • Precise cable adjustment at all times
FIXCAB
ATMI
 Technical data sheet - FIXCAB  (PDF 335Ko)
